INSULATION PIERCING CONNECTORS IPC201FJ

IPC 201FJ specification:

• Main line section(mm2): 25-95
• Branch section(mm2): 25-95
• Nominal current(A): 377
• Bolt Quantity: 1xM8
• (Nm): 13
• Piercing depth(mm): F1318

IPC 201FJ - Piercing Connector for external usage. For Main cables 25-95 and Tap cables 25-95. Maximum load: 377A

• No space required between connections
• No need for a third hand to install

Piercing connector (IPCs) provide a fast, convenient and reliable method of connecting overhead low voltage lines (mains to tap or mains to other mains). All common types of conductors can be interconnected, including insulated aluminum or copper one. The connectors have been tested and are approved for use by different power distribution utilities.
